Cat6 Snagless Patch Cable, 12 Feet Red

SKU: A3L980-12-RED-S

$9.99

Cat6 Snagless Patch Cable, 12 Feet Red, Red, hi-res

Fast and free shipping

30-Day money back guarantee

24/7 Customer support

Cat6 Snagless Patch Cable, 12 Feet Red

$9.99

Color

Cable Length

1 ft 2 ft 3 ft 5 ft 6 ft 7 ft 8 ft 9 ft 10 ft 12 ft 14 ft 15 ft 20 ft 25 ft 50 ft 100 ft

Cat6 Snagless Patch Cable, 12 Feet Red

SKU: A3L980-12-RED-S

$9.99

In Stock

Color

Cable Length

1 ft 2 ft 3 ft 5 ft 6 ft 7 ft 8 ft 9 ft 10 ft 12 ft 14 ft 15 ft 20 ft 25 ft 50 ft 100 ft

Maximize your network speed with a 7-foot high-bandwidth CAT6 cable. Learn More

Ideal for VoIP, video, and file transfers
Exceeds 500MHz in performance tests
Belkin Lifetime Warranty*

Connector

50 micron gold-plated connector

Cable Characteristic

Unshielded twisted pair (UTP)

Cable Type

Cat 6

Characteristic Impedence

100±15Ω @ 1 ~ 550MHz
100±15Ω @ 1 ~ 550MHz

Conductor Construction

Bare Stranded Copper

Conductor Resistance

93.8Ω/km/20°C max

Conductor Size

24AWG x 4pairs

Connector on First End

1 x RJ-45 - male

Connector on Second End

1 x RJ-45 - male

Connectors

RJ45

Dielectric Strength

AC 1.5kV

Flame Retardant Test

Insulation Material

HDPE

Jacket Diameter

5.9±0.15mm

Jacket Material

Mutual Capacitance

56pF/m max

Propagation Delay

536nS/100m max @ 550MHz

Spark Test

2.5kV

Standards Compliance

ISO/IEC 11801; TIA/EIA-568-B.2-1

Structural Return Loss

8.6dB min at 550MHz

At a Glance:

CAT6 Ethernet patch cable for connecting to LANs or the Internet
Ideal for use with 100-1000BASE-T networks
RJ45 plugs with 50-micron gold-plated connectors for clear signal
4 twisted pairs of stranded copper wires prevent crosstalk
Snagless design prevents cracking and breaking

KEY FEATURES

UTP stranded copper wires
Durable PVC jacket
RJ45 plugs with 50-micron gold-plated connectors
Molded strain relief

CONNECT EASILY TO A COMPUTER NETWORK

Upgrade your network and enjoy clean and clear transmissions with the Belkin CAT6 Ethernet Patch Cable. This patch cable lets you connect a laptop or desktop computer to a wall outlet, modem, router or another networking device. It meets the CAT6 standard and is suitable for use with 100/1000BASE-T networks. Patch cables are also handy in home offices and hotel rooms to establish a wired Internet connection.

RJ45 PLUGS WITH GOLD-PLATED CONTACTS FOR A CLEAR SIGNAL

The Belkin CAT6 Ethernet Patch Cable features an RJ45 male connector on each end. Internal load bars ensure accurate plug positioning and consistent high performance, while 50-micron gold-plated connectors resist corrosion and wear and deliver a clean, clear signal.

GIGABIT SPEEDS WITH CAT6 TECHNOLOGY

Made with Unshielded Twisted Pair (UTP) stranded copper wires, this cable meets the CAT6 Ethernet network cable standard and can support Ethernet speeds of up to 1 gigabit per second. Unlike CAT5 technology, CAT6 cables fully use all four pairs of twisted copper wires for greater bandwidth and speed.

LESS CROSSTALK WITH TWISTED PAIR WIRES

The CAT6 Ethernet Patch Cable features 4 UTP 24 AWG (American Wire Gauge) stranded copper wires to reduce electromagnetic interference. Stranded cables are more pliable than solid cables, making them better suited for travel. Plus, the wires are housed in a durable PVC outer jacket for abrasion and corrosion resistance.

Package Includes:

CAT6 Ethernet Patch Cable

Reviews

Questions

Disclaimers

*Belkin Lifetime Warranty on cable product only. See here for details. For this promotion, no refunds will be given under warranty.
